MI 3155 Standard set (ST)

High accuracy current clamp 1000 A / 1 A with jaw opening 52 mm and fixed 1.5 m cable for both load and low range / leakage current measurement and for earth resistance measurement as well.

3-phase test adapter for installation safety testing on 3-phase sockets type 16 A 3CEE.

3-phase adapter with selection switch for installation safety testing on 3-phase sockets type 16 A 3CEE. The adapter allows seamless switching between measurements.

Earth test set for earth resistance measurement on distance up to 50 m; set includes: test lead, 50 m, 2 pcs; test lead, 4.5 m; test lead, 1 m, 2 pcs; earth spikes, 2 pcs; soft carrying bag.

AC/DC Current Clamp with 40 and 300 A range.

Single phase, 3-pin plug commander with TEST, MEM and function selection buttons and RGB LED status indicator.

Extension test lead.

Current clamp 1000 A / 1 A with jaw opening 52 mm for general current measurements and in combination with A 1018 for earth resistance measurement without breaking the loop.

Luxmeter sensor, type B, for high-accuracy illuminance measurement e.g. for emergency lightning inspection.

Illuminance probe for light conditions measurements with 0,1Lux resolution.

Licence key for upgrading the Metrel ES Manager to advanced version with professional report creation and Excel PRO export functionality. Please contact your local dealer for more information on how to order the licence key.

Single phase, 3-wire tip commander with TEST, MEM and function selection buttons, RGB LED status indicator and front LED lamp.

Single phase, 3-pin plug commander with TEST, MEM and function selection buttons and RGB LED status indicator.

Ro-adapter is intended for performing earth resistance measurement in combination with installation safety tester.

Receiver R10K is used for wire tracing, fuse identification and fault finding in low voltage electrical installations.

Additional extension part for Insulated rod for CONTINUITY measurement A 1201.

Insulated rod enables insulation resistance and continuity measurement on hard-to-reach objects, e.g. luminaries.

Connection leads for different measurements.

Very sensitive inductive sensor serves for contactless fuse and cable finding. To be used with A 1191.

Two in one: Test plates for measurement of floor and wall insulation, ∆625 cm2 (acc. to EN 60364-6) and measurement of semi conductivity, 2,5 kg, Ø65 mm (acc. to EN 61340-4-1).

3-wire test lead for measurements on single or three phase electrical installations.

Extension test lead for earth and continuity measurements.

Extension test lead for earth and continuity measurements.

Extension test lead for earth and continuity measurements.

Test probe with fi 4 mm connection is suitable for performing measurements both in mains outlets and in situations when no schuko outlet is present.

Test probe with fi 4 mm connection is suitable for performing measurements both in mains outlets and in situations when no schuko outlet is present.

Test probe with fi 4 mm connection is suitable for performing measurements both in mains outlets and in situations when no schuko outlet is present.

Crocodile clip assures secure and permanent contact during the measurement on bus bars, fixing screws, etc.

Crocodile clip assures secure and permanent contact during the measurement on bus bars, fixing screws, etc.

Crocodile clip assures secure and permanent contact during the measurement on bus bars, fixing screws, etc.

Extension test lead for continuity measurements.

2 pieces of extension test lead for continuity measurements.

The A 1532 EVSE adapter is a special accessory intended for testing Electric Vehicle Supply Equipment (EVSE) together with supported METREL installation testers. It is used for verification of electrical safety and functional testing of EVSE. It is intended for testing Mode 3 EV supply equipment with a type 2 connector. If used together with Metrel AutoSequences®, prebuilt in the newer multifunctional testers, the complete EVSE charging station can be tested (state-by-state) electrically and functionally with a push of a button. It is possible to create a professional station-based report with MESM.

Test probe with fi 4 mm connection is suitable for performing measurements both in mains outlets and in situations when no schuko outlet is present.

Crocodile clip assures secure and permanent contact during the measurement on bus bars, fixing screws, etc.

Adapter for fast battery charging.

Li-Ion Battery pack 7,2V 4400mAh.

Li-Ion Battery pack 7,2V 8800mAh.

4-wire test lead for continuity and impedance measurements on electrical installations.

2-wire test lead for continuity and insulation resistance measurements on electrical installations.

Small carrying bag for transport and storage of test instrument and all belonging standard set and euro set accessories.



Technical data

• Dimensions: 200 x 460 x 245 mm

Large carrying bag for transport and storage of test instrument and all belonging standard set and euro set accessories.



Technical data

• Dimensions: 200 x 600 x 245 mm

Large robust Kelvin crocodile clip for accurate resistance measurements on larger objects.

Large robust crocodile clip for resistance measurements on larger objects.

Large robust crocodile clip for resistance measurements on larger objects.

Barcode scanner for identification of barcode labelled appliances.

Barcode scanner for identification of barcode labelled appliances.

QR / Barcode scanner for identification of barcode labelled appliances.

Extension test leads for 4-wire measurements.

Extension test leads for 4-wire measurements.

Licence key for an additional FW profile and BASIC MESM functionality.

SDK licence key for instrument integration with 3rd party SW. Please contact your local dealr for more information on how to order the licence key.

The aMESM is an advanced portable appliance safety Testing tool for Android devices. The Application is free for download from the Android Market via Google Play. For a full-featured application, a special licence is needed. Please contact your local distributer for further information.

Set of carrying straps for carrying the measuring instrument around the neck allowing free hand use of the tester.

Calibration Box for checking insulation measurements in the field (max. test voltage = 5kV).

Carrying case for MI 3155 EurotestXD together with the Euro set of accessories – for earth resistance testing with or without stakes, testing of impedances, insulation and safety devices in installations, functional tests like power and harmonics, and much more. Some extra space is left available for any additional equipment the user may want to bring along.



Technical data

• Dimensions: 590 x 470 x 270 mm
• Mass: 6.0 kg

Case with foam inserts with slots for a Eurotest multifunctional electrical installation safety tester and MI 3309 BT DeltaGT. Multiple possible instrument & accessory combinations. We recommend the MI 3110 EurotestIT, MI 3309 DeltaPAT, MD 9231 AC/DC current clamp and A 1207 three phase adapter combination.



Technical data

• Dimensions: 590 x 470 x 270 mm
• Mass: 6.0 kg

It can fit for a Eurotest multifunctional electrical installation safety tester and either an A 1532 EVSE adapter or A 1532 XA EVSE adapter. It has an additional large slot for the tester’s accessories or other equipment.



Technical data

• Dimensions: 590 x 470 x 270 mm
• Mass: 6.0 kg

The A 1778 magnetic probe (with a Ø6.6 mm right-angle magnetic adapter and a Ø4 mm socket) is designed for semi-temporary measurement of voltage on steel screw terminal blocks.

Wheels and trolley that can be added to carrying cases for easier transport.

Test probes with 2 mm diameter test tip to fit testing holes incorporated in the various connectors and to reach measurement locations unreachable by test probes with 4 mm diameter test tip.
